400W High power aluminum led tunnel light fitting housing Die cast led tunnel light housing 100w 200w led street light enclosure tunnel light casing

Model No: EK-TL01
Match Power: 100W/150W/200W
Contain Accessories: Aluminum Housing,Toughened Glass, Assembly Screws,Lamp Post pole,
Item         :  IP65 LED Street Lighting Housing
Power      :   100W / 400W
Input Voltage   :   AC220 - 240V, 50/60 HZ
Color Choose :  Dark Gray, Black, Customized etc
Ömrü: ≥50000 Saat

Ürün Özellikleri

  • High quality Aluminum Raw material
  • Silica gel rubber ring IP66 Waterproof
  • 4mm thickness tempering glass with IK09
  • Good structure design ,high conductivity , fast convolution property
  • Tranditional good appearance
  • 304 stainless parts & screws use suit on seaside
  • Standard colors : black, gray and others customized
  • Tooless entry to replace power driver , easy maintain
  • Very high light ratio due to excellent light distribution design lens,
  • Corrosion resistance powder coating 2.0lm thickness

Tüm Seri ve Spesifikasyon

Model koduHousing Size     (Mm)Maç GücüModuel Qty  (Pc)Aksesuarlar
EK-TL01-1M315*90*130   50W1Heatsink body,    supports /PCB/LENS Waterproof Rubber Ring,304 S/S screws,
EK-TL01-2M315*180*130   100W2
EK-TL01-3M315*270*130   150W3
EK-TL01-4M315*360*130   200W4
Legend: Std = ADC12 Aluminum Raw material
Housing Material  :Die-cast  Aluminum +  Aluminum PCB ,LENS
Çalışma sıcaklığı -40℃~50℃ ~ HR

Led Tunnel Light Case Tunnel Light Fixture

EK-TL01

IP65/IP66 , IK08/IK09,

Malzeme: ADC12 Alüminyum

Gövde Rengi : Gri, Siyah,
